Engine Crankshaft Position Sensor Overview

The Vemo V24-72-0160 engine crankshaft position sensor is a direct-fit ignition sensor for select applications that require accurate crankshaft signal input. It is built with a 3-pin, 3-pole connector layout and a compact sensor body for clean integration in the engine management system.

Compatible With 2012-2013 Fiat 500, 2013 Dodge Dart, and 2015-2016 Jeep Renegade. This VEMO sensor is listed for OEM-grade applications and export use, with fitment tied to specific vehicle configurations.

Key Features

• Engine crankshaft position sensor for ignition and engine timing signal input
• 3 connectors and 3 poles for the specified electrical interface
• 12-volt rated design
• Compact dimensions: 72 mm length, 60 mm width, 60 mm height
• Supplied without cable

Detailed Description

The Vemo V24-72-0160 is an engine crankshaft position sensor used to provide the engine control system with crankshaft position data needed for timing and synchronization. Its compact form factor and 3-pin connection layout make it suitable for applications where the original sensor uses the same electrical and physical interface. The part number V24-72-0160 is associated with select Fiat 500, Dodge Dart, and Jeep Renegade applications, including OEM-grade export listings.

This part cross-references Bosch 0261210318 and Standard Ignition PC947 for the same application.

What It Helps Address

• Crankshaft signal loss or inconsistent engine speed input
• Hard starting caused by missing position data
• Engine stalling related to sensor signal interruption
• Misfire or timing-related drivability concerns
• Check engine light conditions tied to crankshaft position faults

Installation Notes and Tips

Verify connector style, mounting depth, and overall dimensions before installation. Confirm the vehicle application against the listed fitment for the Fiat 500, Dodge Dart, or Jeep Renegade before ordering. The sensor is specified without cable, so the existing harness connection must match the OE-style interface.

Quality Assurance

VEMO is listed here with OEM-grade German-made application coverage for the specified fitments. Confirm part number V24-72-0160 against the original sensor before installation.
